Sector-Coupled Data – Triangle Region

Sector-Coupled Data – Triangle Region

31. jan. 2023

The dataset contains aggregated electricity and district heating consumption in kWh together with various weather parameters i.e., temperature, wind speed etc. in the Triangle Region.

Geographical location: Triangle Region of Denmark

Author: Center Denmark (https://www.centerdenmark.com/) in the Digital Energy Hub project

Data source:

TREFOR El-net (https://www.trefor.dk/elnet/)

DMI (https://www.dmi.dk/)

Datasets included as building blocks:

Data sensitivy: Anonymized

Tilgå portalen

Notes:

Date and time format for the datasets follows the ISO 8601 standard.
A validation rule contains a formula or expression that evaluates the data in one or more fields and returns a value of true or false

General information

Name	SectorCoupledDataTriangleRegion
Unique Key	uuid
Time Column	timestamp
Resolution	PT1H
Update Frequency	PT1M
Dataset Published
Data From	2021-11-01

Data Sensitivity

Data Sensitivity	Anonymized
Techniques	Pseudonymization, aggregation, dominance checked.
Pseudonymization column	uuid, station ID,
Aggregation column	heating consumption
Aggregation method	Aggregated geographically in clusters of 20.
Dominance column	heating consumption
Dominance method	No buildings exceeding 25 percent of the total population.

Timestamp

Name	timestamp
Description	A date and time are shown in UTC.
Comment	Timestamp column is representing the date and time in ISO 8601 format: YYYY-MM-DDTHH:MM:SS.
Data Type	Timestamp
Unit
Example	2021-12-01T00:00:00
Validation Rule	Always represented in full quarter-hours, i.e., minutes are either 00, 15, 30 or 45.

UUID

Name	uuid
Title	UUID
Description	Pseudonymized ID of an address.
Comment	A universally unique identifier (UUID) is a 128-bit label.
Data Type	string
Unit
Example	d8c3694d-0203-4996-89e8-452e4a5d592d
Validation Rule

Station ID

Name	station_id
Description	Pseudonymized ID representing a DMI weather station.
Comment	The Station ID column is a categorical variable. The Station ID column has a cardinality of 3 and contains the following categories: 3a8b14af, e22f3e0d, e6a94c27.
Data Type	string
Unit
Example	e22f3e0d
Validation Rule	3a8b14af, e22f3e0d, e6a94c27

Value

Name	active_power_consumption
Description	Aggregated electricity meter measurement values.
Comment
Data Type	decimal
Unit	kWh
Example	0.3
Validation Rule

Name	temp_mean_past1h
Description	The latest hour's mean air temperature measured 2m over terrain.
Comment
Data Type	decimal
Unit	Degree Celsius
Example	5.1
Validation Rule

Name	wind_speed_past1h
Description	The latest hour's mean wind speed measured 10m over terrain.
Comment
Data Typedecimal
Unit	m
Example	0.7
Validation Rule

Name	humidity_past1h
Title	Mean Humidity
Description	The latest hour's mean for relative humidity measured 2m over terrain.
Comment
Data Type	decimal
Unit	Degree Celsius
Example	90.0
Validation Rule

Name	radia_glob_past1h
Description	The mean intensity of global radiation in the latest hour.
Comment
Data Type	decimal
Unit	W/m²
Example	0.0
Validation Rule

Name	forward_temperature
Description	The Forward Temperature of the district heating meter water supply.
Comment
Data Type	decimal
Unit	Degree Celsius
Example	60.9
Validation Rule

Name	return_temperature
Description	The Return Temperature of the district heating meter water supply.
Comment
Data Type	decimal
Unit	Degree Celsius
Example	43.1
Validation Rule

Name	heating_consumption
Description	The heating consumption of the district heating meter water supply.
Comment
Data Type	decimal
Unit	kWh
Example	1.0
Validation Rule

Name	flow_rate
Description	The Flow Rate of the district heating meter water supply.
Comment
Data Type	decimal
Unit	l/h
Example	60.0
Validation Rule

Name	volume_consumption
Description	The Volume Consumption of the district heating meter water supply.
Comment
Data Type	decimal
Unit	m³
Example	0.023
Validation Rule
